Availability: In stock
Product Code:29525
Description:
- Guiding video to top-tier security
- Efficient video monitoring for any site
- Video monitoring — exactly how it's meant to be
- Complete awareness with a customizable video wall
- Smooth archive navigation
- Rapid and encrypted data transfer
- Easy integration through ONVIF and RTSP
- Instant event-to-video alarm verification
- Built-in motion detection
- Verified evidence with no effort
- Discover future-proof hardware
- HDMI output / two USB ports / AC/DC power connectors
- LED indicator
- Quiet fan for active cooling
- Hard drive latch
- Rule your video surveillance
- Hassle-free installation and setup
- Established security experience
Details:
Video
- Video input : 16 channels
- Recording resolution : 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
- HDMI output resolution : 1920 × 1080 / 1600 × 1200 / 1280 × 1024 / 1280 × 720 px
- Live view / playback resolution : 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 720p / D1 / VGA / CIF
Decoding
- Format : H.265 / H.264 / JetSparrow
- Capability : 1 × channel at 8MP , 3 × channel at 5MP / 4 × channel at 4MP / 4 × channel at 1080p / 10 × channel at 720p / 16 × channel at 1024 × 576 px
- Live view window division : templates : 1 / 4 / 9 / 16 / 5+1 / 7+1 views / custom : up to 10×10 views
- Synchronous playback : 16 channels
Intelligent video analytics
- Motion detection : Ajax camera : 16 channels / NVR : 16 channels
- AI object detection : Ajax camera : 16 channels
Interface
- HDD : 1 × SATA : supports hard drive with up to 16 TB capacity (3.5” form factor) ***HDD is not included
- Network : 1 × RJ-45 self-adaptive Ethernet (10/100 Mbps)
- USB : rear panel : 1 × USB 2.0 (Type-A) / side panel: 1 × USB 2.0 (Type-A) (To connect a keyboard, mouse, or a USB flash drive)
Network
- Bandwidth : incoming : up to 80 Mbps / outgoing : up to 40 Mbps
- Protocol : HTTP / HTTPS / TCP/IP / IPv4 / IPv6 / SNMP / RTSP / UDP / DHCP / DNS / DDNS
- Interoperability : ONVIF
Key features
- Supported devices : Ajax cameras / IP cameras using ONVIF (Profile S/T) or RTSP
- Built-in video management system : Integrated video wall interface with live camera feeds / Smart event filters for quick access to relevant footage / Interactive timeline with preview navigation for efficient playback and incident review
- Visual verification of Ajax system alarms
- Privacy
Power supply
- Main : 110–240 V / 50/60 Hz / 0.6 A
- Power consumption : up to 24 W
- Clock battery : CR2032 battery / 3 V
Enclosure
- Dimensions : 212 × 212 × 64 mm
- Weight : 782 g
- Operating temperature range : from 0 °C to +40 °C
- Operating humidity : up to 75%
- Protection class : IP20
