- Phase
- Single Phase
- Form Factor
- Rackmount, Tower
- UPS Topology
- Online Double Conversion
- Energy Saving Technology
- ECO Mode Efficiency ＞ 98%
- Active PFC Compatibility
- Yes
- Parallel Expansion (Max. Units)
- 4 (Optional)
- Generator Compatibility
- Yes
- Nominal Input Voltage ( Vac )
- 230 ± 10%
- Input Voltage Range ( Vac )
- 110 ~ 300
- Input Frequency ( Hz )
- 50 ± 10, 60 ± 10
- Input Frequency Detection
- Auto-sensing
- Rated Input Current ( A )
- 45.5
- Input Power Factor
- 0.99
- Input Connector Type
- Hardwire Terminal Block
- Capacity (VA)
- 10000
- Capacity (Watts)
- 10000
- On Battery Waveform
- Pure Sine Wave
- On Battery Voltage(s) ( Vac )
- 208 ± 1 %, 220 ± 1 %, 230 ± 1 %, 240 ± 1 %
- Output Voltage Setting
- Configurable
- On Battery Frequency ( Hz )
- 50 ± 0.5%, 60 ± 0.5%
- Output Frequency Setting
- Configurable
- Power Factor
- 1
- ECO Mode Voltage Tolerance
- ± 10 %
- Overload Protection
- Internal Current Limiting, Circuit Breaker, Fuse
- Crest Factor
- 3 : 1
- Harmonic Distortion (Linear Load)
- THD＜1.5%
- Harmonic Distortion (Non-linear Load)
- THD＜3%
- Internal Bypass
- Automatic Bypass, Manual Bypass
- Maintenance Bypass
- Yes
- Outlet(s) - Total
- 9
- Outlet Type
- Hardwire Terminal Block x 1, IEC C13 x 4, IEC C19 x 4
- Typical Transfer Time ( ms )
- 0
- Runtime at Half Load ( min )
- 11.2
- Runtime at Full Load ( min )
- 2.9
- Typical Recharge Time ( Hours )
- 4
- Maximum Charging Current ( A )
- 4
- Start On Battery
- Yes
- Smart Battery Management (SBM)
- Yes
- User-replaceable
- Yes - Qualified Personnel Only
- Battery Type
- Sealed Lead-acid
- Replacement Battery Pack (RBP)
- RBP0191
- Replacement Battery Pack (RBP) Quantity ( pcs )
- 2
- Battery Quantity (Each RBP) ( pcs )
- 10
- Compatible Extended Battery Module (EBM)
- BPS240V9ART3U
- Extended Battery Module Auto-detection
- Yes
- Max. EBM Quantity ( pcs )
- 10
- Surge Suppression ( Joules )
- 1335
- EMI/RFI Filtration
- Yes
- LCD Panel
- Yes
- LCD Types
- Color LCD
- LCD Orientation
- Rotatable LCD – Manual
- Tiltable LCD Panel
- 15°
- LCD Information Display
- Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log
- LCD Setting & Control
- Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning, Communication, Event & Log, Security Setting
- LED Indicators
- Power On
- HID Compliant USB Port(s)
- 1
- Serial Port
- RS232
- Dry Contact (with Relay)
- Yes
- Emergency Power Off (EPO) Port
- Yes
- Audible Alarms
- Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery
- Management Cable ( pcs )
- Power Cord x4, USB Cable x1
- Power Management Software
- PowerPanel Business (Recommended)
- SNMP/HTTP Remote Monitoring
- Yes - RMCARD205 included
- PowerPanel Cloud Service
- Yes - 30 Days Free Trial with PowerPanel Personal/Business
- Enclosure Construction
- Metal
- Color
- Black
- Rackmount Rail
- Yes
- Rackmount Ears
- Yes
- Dimensions (WxHxD) (mm.)
- 433 x 213.5 x 661
- Weight (kg.)
- 80.4
- Installed Rack Height ( U )
- 5
- Operating Temperature (°C)
- 0 ~ 40
- Operating Relative Humidity (Non-condensing) ( % )
- 0 ~ 95
- Operating Elevation ( meters )
- ≤1000, Load Derated 1% per 100m from 1000m and 2000m
- Storage Temperature (°C)
- -15 ~ 45
- Storage Relative Humidity (Non-condensing) ( % )
- 0 ~ 95
- Storage Elevation ( meters )
- 0-15,000 meters
- Online Thermal Dissipation ( BTU/hr )
- 2047
- Audible Noise at 1.0M from Surface of Unit ( dBA )
- 60
- Certifications
- CE
- RoHS
- Yes
- Rack/Tower Convertible Configurations
- Yes
