- Image Sensor
- 5 MP CMOS
- Max. Resolution
- 2880 (H) × 1620 (V)
- Scanning System
- Progressive
- Electronic Shutter Speed
- PAL: 1/25 s–1/100,000 s / NTSC: 1/30 s–1/100,000 s
- Min. Illumination
- 0.0001 lux@F1.0 (Color, 30 IRE) / 0 lux (Illuminator on)
- S/N Ratio
- >65 dB
- Illumination Distance
- Warm light: 50 m (164.04 ft)
- Illuminator On/Off
- Control Auto/Manual
- Illuminator Number
- 4 (Warm light)
- Angle Adjustment
- Pan: 0°–360° / Tilt: 0°–90° / Rotation: 0°–360°
- Lens Type
- Fixed-focal
- Lens Mount
- M12
- Focal Length
- 2.8 mm
- Max. Aperture
- F1.0
- Field of View
- 2.8 mm : H: 109.6° / V: 57.5° / D: 131°
- Iris Control
- Fixed
- Close Focus Distance
- 2.8 mm: 2.0 m
- Video Frame Rate
- CVI : PAL: 5M@25 fps / 5M@12.5 fps / NTSC : 5M@25 fps / 5M@10 fps / AHD : PAL : 4M@25 fps / NTSC: 4M@30 fps / TVI : PAL: 5M@20 fps / NTSC : 5M@20 fps / CVBS : PAL: 960H / NTSC : 960H
- Resolution
- 5M (2880 × 1620) / 4M (2560 × 1440) / 960H (960 × 576/960 × 480) / TVI 5M 16:9 (2960 × 1665)
- Day/Night
- Color
- WDR
- 130 dB
- White Balance
- Auto
- Gain Control
- Auto
- Noise Reduction
- 3D NR
- Motion Detection
- Yes (It needs to be controlled through the XVR)
- Illumination Mode
- Smart Light
- Mirror
- Yes (It needs to be controlled through the XVR)
- Certifications
- CE-LVD: EN 62368-1 / CE-EMC: EN 55032 / EN 55035 /
- Built-in Mic
- Yes, built-in dual Mic
- Camera Audio
- CVI
- Pick-up Distance
- 12 m (39.37 ft)
- Video Output
- Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch)
- Power Supplyc
- 12 VDC (±30%)
- Power Consumption
- Max 5.8 W (12 VDC, LED on)
- Operating Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity
- <95% (RH), non-condensing
- Storage Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Storage Humidity
- <95% (RH) / non-condensing
- Protection
- IP67
- Anti-corrosion Level
- Basic Protection
- Casing Material
- Metal front cover + plastic rear barrel + metal bracket
- Product Dimensionsc
- 186.5 mm × 75 mm × 82.2 mm (L × W × H)
- Net Weight
- 0.35 kg (0.77 lb)
- Gross Weight
- 0.49 kg (1.08 lb)
- Installation
- Wall mount / ceiling mount / vertical pole mount
