Availability: In stock
Product Code:30080
Description:
- Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.
- Max. decoding capability: 40 × 1080p@30 fps or 10 × 8MP@30 fps.
- Max. 448/448/448 Mbps incoming/recording/outgoing bandwidth.
- Supports IP cameras with a resolution up to 32 MP.
- Supports 8K HDMI output.
- Supports iSCSI.
- AI by Recorder supports 4-channel face detection and recognition, up to 20 face databases and 30,000 face images; 4-channel video metadata; 8-channel perimeter protection; 16-channel SMD Plus; 4-channel AcuPick.
- AI by Camera supports face detection and recognition, perimeter protection, SMD, metadata, AcuPick, ANPR, stereo analysis, heat map, people counting, PPE detection, smart object detection and smart sound detection.
- Supports EPTZ, and one-click arming and disarming.
Details:
System
Main Processor: Industrial-grade processor
Operating System: Embedded Linux
Operating Interface: Web / Local GUI
AI
AI by Recorder: Face detection / face recognition / video metadata (human / motor vehicles and non-motor vehicles) / perimeter protection / SMD Plus / AcuPick
AI by Camera: Face detection / face recognition / video metadata (human / motor vehicles and non-motor vehicles) / perimeter protection / SMD / stereo analysis / crowd distribution / people counting / ANPR / vehicle density / heat map / PPE detection / smart object detection / smart sound detection / AcuPick
AcuPick Performance of AI by Recorder (1080P) (Number of Channels): 4 channels
AcuPick Performance of AI by Camera (1080P) (Number of Channels): Max. 32-channel / 1 combined event per channel/s
Perimeter Protection
Perimeter Performance AI by Recorder (Number of Channels): 8 channels / 10 IVS rules for each channel
Perimeter Performance of AI by Camera (Number of Channels): All channels (32 targets/s)
Face Detection
Face Attributes: Gender / age group / glasses / expressions / face mask / beard
Face Detection Performance of AI by Recorder (Number of Channels): 4 channels (up to 12 face images/s each channel)
Face Detection Performance of AI by Camera (Number of Channels): All channels (32 targets/s)
Face Recognition
Face Database Capacity: Up to 20 face databases with 30,000 images / with a total capacity of 3.75 GB. Name / gender / birthday / address / credential type / credential No. / countries & regions and state can be added to each face image
Face Recognition Performance of AI by Recorder (Number of Channels): 1. 24-channel FD (by camera) + FR (by recorder), image stream: 24 face images/s / 2. 4-channel FD (by recorder) + FR (by recorder), video stream: 24 face images/s
Face Recognition Performance of AI by Camera (Number of Channels): All channels (32 targets/s)
SMD
SMD Plus by Recorder: 16 channels / Secondary filtering for human and motor vehicle / reducing false alarms caused by leaves / rain and lighting condition change
SMD by Camera: All channels (64 targets/s)
Video Metadata
Metadata Performance of AI by Recorder (Number of Channels): 4 channels / 22 attributes extraction
Metadata Performance of AI by Camera (Number of Channels): All channels (16 targets/s)
People Attributes: Top color / top type / bottom color / bottom type / hat / bag / age / gender and umbrella
Motor Vehicle Attributes: License plate / plate color / vehicle body / vehicle model / vehicle logo / calling / seatbelt / vehicle interior / vehicle registration location
Non-motor Vehicle Attributes: Vehicle model / vehicle color / number of persons / helmet
Vehicle License Plate Comparison
ANPR by Camera (Number of Channels): All channels (8 targets/s)
License Plate Database Capacity: 1. Create up to 20,000 plate numbers / 2. Blocklist and allowlist
Audio and Video
Access Channel: 32 channels
Network Bandwidth: AI disabled: 448 Mbps incoming / 448 Mbps recording / 448 Mbps outgoing / AI enabled: 200 Mbps incoming / 200 Mbps recording / 200 Mbps outgoing
Resolution: 32 MP / 24 MP / 16 MP / 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / 720p / 960p / D1 / CIF / QCIF
Decoding Capability: AI disabled: 2-channel 32 MP@25 fps / 2-channel 24 MP@25 fps / 5-channel 16 MP@30 fps / 6-channel 12 MP@30 fps / 10-channel 8 MP@30 fps / 13-channel 6 MP@30 fps / 16-channel 5 MP@30 fps / 20-channel 4 MP@30 fps / 32-channel 1080p@30 fps – AI enabled: 1-channel 32 MP@25 fps / 2-channel 24 MP@25 fps / 4-channel 16 MP@30 fps / 5-channel 12 MP@30 fps / 8-channel 8 MP@30 fps / 10-channel 6 MP@30 fps / 12-channel 5 MP@30 fps / 16-channel 4 MP@30 fps / 32-channel 1080p@30 fps
Video Output: 1 VGA / 1 HDMI / VGA: 1920 × 1080 / 1280 × 1024 / 1280 × 720 / HDMI: 7680 × 4320 / 3840 × 2160 / 1920 × 1080 / 1280 × 1024 / 1280 × 720 / Heterogeneous video source output for HDMI and VGA
Multi-screen Display: Main Screen: 1 / 4 / 8 / 9 / 16 / 25 / 36 / Sub Screen: 1 / 4 / 8 / 9 / 16
Third-party Camera Access: ONVIF / Panasonic / Sony / Axis / Arecont / Pelco / Canon / Hanwha
Compression Standard
Video Compression: Smart H.265+ / H.265 / Smart H.264+ / H.264 / MJPEG
Audio Compression: G.711a / G.711u / PCM / G726
Network
Network Protocol: HTTP / HTTPS / TCP/IP / IPv4 / IPv6 / UDP / NTP / FTP / SFTP / DHCP / DNS / SMTP / UPnP / DDNS / SNMP / Alarm Server / IP Search (Supports IP camera / DVR / NVS / etc.) / Multicast / P2P / Auto Registration / iSCSI
Mobile Phone Access: iOS / Android
Interoperability: ONVIF 24.12 (Profile T / Profile S / Profile G / Profile M) / CGI / SDK
Browser: Chrome / IE / Safari / Edge / Firefox
Recording Playback
Multi-channel Playback: Up to 16 channels
Record Mode: General / motion detection / intelligent / alarm / POS
Backup Method: USB device and network
Playback Mode: Instant playback / general playback / event playback / target video / video clip / tag playback / smart playback (face and motion detection)
Storage
Disk Group: Yes
Alarm
General Alarm: Motion detection / local alarm / alarm box / camera external alarm / network alarm / scene changing / PIR alarm / thermal alarm
Anomaly Alarm: Camera offline / storage error / disk full / IP conflict / MAC conflict / login lock / abnormal behavior of fan / cybersecurity exception
Intelligent Alarm: Face detection / perimeter protection / face recognition / video metadata (human / motor vehicles and non-motor vehicles) / SMD Plus / stereo analysis / crowd distribution / people counting / ANPR / vehicle density / heat map / PPE detection / smart object detection / smart sound detection
Alarm Linkage: Record / snapshot (panoramic) / local alarm output / IPC external alarm output / audio / buzzer / log / preset / email
Port
Audio Input: 1-channel RCA
Audio Output: 1-channel RCA
Alarm Input: 4 channels
Alarm Output: 2 channels
Disk Interface: 2 SATA ports / each disk can contain up to 20TB. This limit varies depending on the environment temperature
RS-232: 1
RS-485: 1
USB: 2 (1 front USB 2.0 port / 1 rear USB 3.0 port)
HDMI: 1
VGA: 1
Network Port: 1 (10 / 100 / 1000 Mbps Ethernet port / RJ-45)
General
Power Supply: 12 VDC / 4 A
Power Consumption: Total output of NVR is ≤ 10 W (without HDD)
Net Weight: 1.55 kg (3.42 lb)
Gross Weight: 2.77 kg (6.11 lb)
Product Dimensions: 375.0 mm × 284.8 mm × 56.0 mm (14.76" × 11.21" × 2.20") (W × D × H)
Packaging Dimensions: 427.0 mm × 137.0 mm × 356.0 mm (16.81" × 5.39" × 14.02") (W × D × H)
Operating Temperature: –10 °C to +55 °C (+14 °F to +131 °F)
Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
Operating Humidity: 10%–93% (RH) / non-condensing
Certifications: CE-EMC: EN 55032:2015+A1:2020 / EN IEC 61000-3-2:2019+A1:2021 / EN 61000-3-3:2013+A1:2019+A2:2021 / EN 55035:2017+A11:2020 / EN 50130-4:2011+A1:2014 / CE-LVD: EN 62368-1:2014
