Dahua NVR 64ch 8HDD 384mbps H265+ NVR5864-EI
Dahua NVR 64ch 8HDD 384mbps H265+ NVR5864-EI
2.482,00 €

Or contact us directly:

📞 25 102 760
📱 96 401 000

Pairs well with

Popular add-ons for this product

Specifications

System3
Main Processor
Industrial-grade processor
Operating System
Embedded Linux
Operating Interface
Web, Local GUI
AI3
AI by Recorder
Face detection; face recognition; perimeter protection; SMD Plus
AI by Camera
Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map
AcuPick AI by Camera + Recorder
Max. 16-channel, 1 combined event per channel/s
Perimeter Protection2
Perimeter Performance AI by Recorder (Number of Channels)
4 channels, 10 IVS rules for each channel
Perimeter Performance of AI by Camera (Number of Channels)
16 channels
Face Detection3
Face Attributes
Gender; age group; glasses; expressions; face mask; beard
Face Detection Performance of AI by Recorder (Number of Channels)
2 channels (up to 12 face images/s each channel)
Face Detection Performance of AI by Camera (Number of Channels)
16 channels
Face Recognition4
Face Database Capacity
Up to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.
Face Recognition Performance of AI by Recorder (Number of Channels)
1. 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s
2. 2-channe FD (by recorder) + FR (by recorder), video stream
12 face images/s
Face Recognition Performance of AI by Camera (Number of Channels)
16 channels
SMD Plus2
SMD Plus by Recorder
8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change
SMD Plus by Camera
16 channels
Video Metadata4
Metadata Performance of AI by Camera (Number of Channels)
8 channels
Human Attributes
Top color, top type, bottom color, bottom type, hat, bag, age, gender and umbrella
Motor Vehicle Attributes
License plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location
Non-motor Vehicle Attributes
Vehicle model, vehicle color, number of persons, helmet
Vehicle License Plate Comparison2
ANPR by Camera (Number of Channels)
8 channels
License Plate Database Capacity
1. Create up to 20,000 plate numbers / 2. Blocklist and allowlist
Audio and Video10
Access Channel
64
Network Bandwidth
AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing / AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
Resolution
32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF
Decoding Capability
AI disabled: 2-channel 32 MP@20 fps; 2-channel 24 MP@20 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps / AI enabled : 1-channel 32 MP@20 fps; 1-channel 24 MP@20 fps; 2-channel 16 MP@30 fps; 4-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 8-channel 5 MP@30 fps; 12-channel 4 MP@30 fps; 24-channel 1080p@30 fps
Video Output
2 VGA :1920 × 1080, 1280 × 1024, 1280 × 720 /  2  HDMI:3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
Heterogeneous video source output for HDMI1 and HDMI2
Simultaneous video source output for VGA1 and HDMI1
Simultaneous video source output for VGA2 and HDMI2
Multi-screen Display
Main screen: 1/4/8/9/16/25/36/64 / Sub screen: 1/4/8/9/16
Third-party Camera Access
ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Samsung
Compression Standard2
Video Compression
Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
Audio Compression
G.711a; G.711u; PCM; G726
Network5
Network Protocol
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCSI
Mobile Phone Access
iOS; Android
Interoperability
ONVIF 22.06 (Profile T; Profile S; Profile G); CGI; SDK
Browser
Chrome;IE;Safari;Edge;Firefox
Network Mode
Multi-address mode, load balance, fault tolerance and other network port binding modes
Recording Playback4
Multi-channel Playback
Up to 16 channels
Record Mode
General, motion detection; intelligent; alarm; POS
Backup Method
USB device and network
Playback Mode
Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection)
Storage2
Disk Group
Yes
RAID
RAID 0/1/5/6/10
Alarm4
General Alarm
Motion detection; privacy masking; local alarm
Anomaly Alarm
Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan; cybersecurity exception
Intelligent Alarm
Face detection; perimeter protection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map
Alarm Linkage
Record; snapshot (panoramic); local alarm output; IPC external alarm output; access controller; audio; buzzer; log, preset; email
Port12
Audio Input
1-channel RCA
Audio Output
2-channel RCA
Alarm Input
16 channels
Alarm Output
8 channels (1-channel 12 V 1 A output)
HDD Interface
8 SATA ports, each disk can contain up to 16 TB. This limit varies depending on the environment temperature.
eSATA
1
RS-232
1
RS-485
2 (1 port for half-duplex serial communication, 1 port for full-duplex serial communication)
USB
4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports)
HDMI
2
VGA
2
Network Port
2(10/100/1000 Mbps Ethernet port, RJ-45)
General11
Power Supply
100–240 VAC, 50-60 Hz
Power Consumption
Total output of NVR is ≤ 13 W (without HDD)
Net Weight
6.4 kg
Gross Weight
9.01 kg
Product Dimensions
439.9 mm × 457.9 mm x 89.0 mm (W ×D × H)
Packaging Dimensions
570.0 mm × 570.0 mm x 226.0 mm  (W ×D × H)
Operating Temperature
–10 °C to +55 °C
Storage Temperature
–20 °C to +60 °C
Operating Humidity
10%–93% (RH)
Installation
Rack or desktop
Certifications
FCC: 47 CFR FCC Part15, SubpartB, Class A / CE-EMC: EN 55032: 2015+A1: 2020; EN IEC 61000-3-2: 2019+A1: 2021; EN 61000-3-3: 2013+A1: 2019+A2: 2021; EN 55035: 2017+A11: 2020; EN 50130-4: 2011+A1: 2014 / CE-LVD: EN 62368-1: 2014
  • Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format
  • Max. decoding capability: 32 × 1080p@30 fps or 32 × 2MP@30 fps
  • Support AcuPick with Max. 16-Channel
  • Support N+M cluster
  • Support Raid0/1/5/6/10
  • Max. 384 Mbps incoming/recording/outgoing bandwidth
  • AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
  • AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting
  • Security baseline 2.3
