Availability: In stock
Product Code:29408
Description:
- Dolynk cloud version: DMSS 2.0.30 and above, Dolynk Care 2.50.20 and above
- 8-channel two-way talk over coaxial cable allows for seamless communication between the camera, client and recorder
- 8-channel SMD Plus for analog channels or 6-channel SMD by camera which allows the device to trigger accurate alarms for humans and vehicles
- 8-channel AI Coding saves on storage and bandwidth while maintaining the details of targets in videos
- Supports HDCVI, AHD, TVI, CVBS and IP video input
- Supports up to 12-channel IP camera input and each channel can be up to 6 MP. The incoming bandwidth reaches 32 Mbps
- Supports accessing Wi-Fi cameras, making it suitable for a wide range of scenes
- Smart H.265+ and H.265 dual-stream video compression
Details:
System
- Main Processor: Industrial-grade processor
- Operating System: Embedded LINUX
- Operating Interface : Web; Local GUI
SMD
SMD Plus by Recorder
- 8 channels : Secondary filtering for human and vehicle, reducing false alarms caused by leaves, rain and lighting condition change
- SMD by Camera : 12 channels
Irregular Black Block Masking
- Irregular Black Block Masking by Recorder : 1 channel
Audio and Video
- Analog Camera Input : 8 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect
- Camera Input : CVI: 5 MP@25 fps; 5 MP@20 fps; 5 MP@10/12.5 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@50/60 fps; 720p@25/30fps. / TVI: 5 MP(2560 x 1944)@20 fps; 5 MP(2960 x 1665)@20 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps. / AHD: 5 MP@20 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps.
- IP Camera Input : Up to 6 channels of IPC access / 2 IP channels by default + 4 channels (analog channels are converted to IP channels) / Incoming bandwidth: 32 Mbps, recording bandwidth: 32 Mbps and outgoing bandwidth: 32 Mbps
- Encoding Capacity : Main stream : 5 MP Mode: 4-ch 5 MP@(1 fps-6 fps); others 5M-N@(1fps-12 fps) / 5M-N Mode: 5M-N@(1 fps –12 fps); 4M-N/1080p@(1fps–15 fps); 1080N/720p/960H/D1/CIF@(1 fps–25/30 fps) / Sub stream: D1/CIF@(1 fps–15 fps)
- Dual-stream : Yes
- Video Bit Rate : 32 kbps–6144 kbps
- Audio Sampling : 8 kHz, 16 bit
- Audio Bit Rate : 64 kbps
- Video Output : 1 HDMI, 1 VGA / HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 / VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- Multi-screen Display : When IP extension mode not enabled: 1/4 / When IP extension mode enabled: 1/4/6
- Third-party Camera Access : Panasonic; Sony; Hanwha; Axis; Arecont; ONVIF
Compression Standard
- Video Compression : AI Coding; Smart H.265+; H.265; Smart H.264+; H.264
- Audio Compression : G.711a; G.711u; PCM
Network
- Interface: 1 RJ-45 Port (100M)
- Network Function: HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, SNMP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
- Smart Phone: iPhone, iPad, Android
- Interoperability : ONVIF 24.12 (Profile T; Profile S; Profile G); CGI; SDK
Recording Playback
- Record Mode : General; alarm; motion detection
- Recording Playback : 1/4/9
- Backup Method : USB device and network
- Playback Mode : Instant playback; general playback; event playback; tag playback; smart playback
Alarm
- General Alarm : Motion detection; HDCVI alarm; camera external alarm; network alarm; PIR alarm
- Anomaly Alarm : Error (no disk, disk error, low space, low quota space; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline
- Intelligent Alarm : SMD Plus
- Alarm Linkage : Record; snapshot (panoramic); IPC external alarm output; audio; buzzer; log; preset; email
Ports
- Audio Input : 1-channel RCA / 8-channel BNC (Coaxial Audio)
- Audio Output : 1-channel RCA
- Two-way Talk : Coaxial two-way talk: 8-channel BNC / Local and network user two-way talk: Shares the same audio input with the first channel
- Disk Interface : 1 SATA port, up to 16 TB. This limit varies depending on the environment temperature.
- USB : 2 (2 rear USB 2.0 ports)
- HDMI : 1
- VGA : 1
- Network Port : 1 (10/100 Mbps Ethernet port, RJ-45)
General
- Power Supply : 12 VDC, 1.5 A
- Power Consumption : <7 W (without HDD)
- Net Weight : 0.59 kg
- Gross Weight : 1.14 kg
- Product Dimensions : 197.0 mm × 204.3 mm × 41.5 mm (W × D × H)
- Packaging Dimensions : 332.0 mm × 64.0 mm × 240.0 mm (W × D × H)
- Operating Temperature : –10 °C to +45 °C
- Storage Temperature : –20 °C to +60 °C
- Operating Humidity : 10%–90% (RH), non-condensing
- Installation : Desktop
Certifications
- CE-LVD: IEC 62368-1:2014
- CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014
