Availability: In stock
Product Code:29514
Description:
- Critical insight — in detail or in full view
- Adjustable 2.8–12 mm focal length
- Real-time autofocus for sharp visuals
- IR illumination range: up to 60 m
- White light illumination range: up to 40 m
- Balanced lighting in every frame
- Watch the essential with the power of AI
- Smooth archive navigation
- Security system integration for coordinated response
- Data protection and privacy without compromise
- Hardwired for upgrades and retrofits
- Easy integration through ONVIF and RTSP
Details:
Camera
- Image sensor : 5 MP CMOS, 1/2.7" type
- Lens focal length : 2.8–12.0 mm
- Maximum aperture : f/1.6
- Lens iris type : fixed
- Lens focal type : varifocal
- Field of view : horizontal: 31°–111° / vertical: 17°–57° / diagonal: 35°–135°
- Maximum illumination distance : white LED: up to 40 m / IR LED: up to 60 m
Video
- Resolution : 5 MP (2880 × 1620) / 4 MP (2560 × 1440) / 3 MP (2304 × 1296) / 2 MP (1920 × 1080) / 0.6 MP (1024 × 576)
- Frame rate : up to 25 fps
- Image rotation : 0°, 90°, 180°, 270°
- Video codec : H.265 / H.264
- Dynamic range : 120 dB (True WDR)
- Storage : microSD / Ajax NVR (Camera supports microSD cards up to 256 GB. The memory card must be Class V30 or faster. The card is not included in the complete set)
Audio
- Built-in microphone : 1
- Audio codec : G.711 µ-law / G.711 A-law / G.726 / G.722
Intelligent video analytics
- Motion detection : The camera detects motion using software-based image frame analysis
- AI object detection : People / Pets / Vehicles / Line-crossing
Network
- Port : 1 × RJ45 self-adaptive Ethernet (10/100 Mbps)
- Protocol : HTTP / HTTPS / TCP/IP / IPv4 / IPv6 / SNMP / RTSP / UDP / DHCP / DNS / DDNS
- Interoperability : ONVIF (Profile S/T*) * Profile T is supported for basic streaming and configuration. Advanced features such as metadata, event handling, or edge recording may not be available
Alarm port
- Lines for third-party devices : 2
- Alarm IN type : NO / NC
- Alarm IN max voltage : 5 V⎓
- Alarm OUT operating range : 48 V⎓ / 300 mA
Audio port
- Lines for third-party devices : 2
- Audio IN type : external microphone input
- Audio IN settings : gain / enable/disable
- Audio OUT type : speaker output
Key features
- Video transmission : JetSparrow
- Focal length change : autofocus / manual focus control
Sabotage protection
- mTLS
- Authentication
- Secure Boot
- OTA signature verification
- Accelerometer
Power supply
- PoE standard : 802.3at/af (Class 3)
- External power connector type : screw terminal connector (2 pin)
- Power consumption : maximum: up to 12 W / average: up to 6 W
- Power supply unit : 12 V⎓ ±20% / 1 А
Enclosure
- Dimensions : 242 × 90 × 90 mm
- Weight : 940 g
- Operating temperature range : from −40 °C to +60 °C
- Operating humidity : up to 90%
- Protection class :IP67 / IK10 / IK08
