- Double the storage. Double the confidence
- Built to stand out
- Continuous operation and easy maintenance with hot-swappable HDDs
- Resilient storage with two recording modes and support for two HDDs
- Effortless integration with existing systems and third-party monitoring software
- Outstanding monitoring experience with Ajax apps and local VMS
- Always-on recording without service breaks
- Full story preserved with two-drive recording
- Keeping track of critical events — at the desk or on the go
- Easy integration through ONVIF and RTSP
- Complete awareness with a customizable video wall
- Smooth archive navigation
- Instant event-to-video alarm verification
- Rapid and encrypted data transfer
- Built-in motion detection
- Privacy by design
- Hardwired for any setup
Reolink BP Outdoor Battery Camera 4K PTZ Dual Lense TRACKMIX-4K (B770) + 6W Panel (Hard Bundle)
219,99 €
Reolink BUNDLE BP4G 4K GO Ultra (G340) + 6W Solar Panel (25485+24757)
169,99 €AJAX SURVEILLANCE NVR 16ch HDMI 160Mbps 4K Hot-Swap H2DAC
773,00 €
In stock · delivery across CyprusFree pickup in Limassol
Pairs well with
Popular add-ons for this product
Code: 27960- Length: 1.8 m
- Power: 100W
In stock · delivery across CyprusFree pickup in Limassol19,99 €Add to cart
More options
Similar IP Cameras & NVR in a similar price range
Specifications
Video4
- Video input
- 16 channels
- Recording resolution
- 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
- HDMI output resolution
- 3840 × 2160 / 1920 × 1080 / 1280 × 1024 / 1280 × 720 px
- Live view / playback resolution
- 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / 720p / D1 / VGA / CIF
Decoding3
- Format
- H.265 / H.264 / JetSparrow
- Live view window division
- templates : 1 / 4 / 9 / 16 / 25 / 5+1 / 7+1 / 12+1 views / custom: up to 10×10 views
- Synchronous playback
- 4 channels
Intelligent video analytics2
- Motion detection
- Ajax camera : 16 channels / NVR : 16 channels
- AI-powered object detection
- Ajax camera : 16 channels
Interface4
- HDD
- 2 × SATA III : supports hard drives with up to 16 TB capacity (2.5" and 3.5" form factors) ***HDDs are not included
- Network
- 1 × RJ45 self-adaptive Ethernet (10/100/1000 Mbps)
- USB
- rear panel : 2 × USB 2.0 (Type-A) (For connecting a keyboard, mouse, or USB Audio Device Class devices) (Audio IN/Audio OUT).
- front panel
- 1 × USB 2.0 (Type-A) (To connect a USB flash drive)
Network3
- Bandwidth ; incoming
- up to 160 Mbps / outgoing: up to 160 Mbps
- Protocol
- HTTP / HTTPS / TCP/IP / IPv4 / IPv6 / UPnP / SNMP / RTSP / UDP / SMTP / NTP / DHCP / DNS / DDNS
- Interoperability
- ONVIF
Key features7
- Supported devices
- Ajax cameras / IP cameras via ONVIF (Profile S/T) or RTSP
- Redundancy mode
- Simultaneous recording of the same video streams to two storage devices to ensure data redundancy and reliability
- Split mode
- Sequentially distributes video streams across multiple storage devices to balance the load and optimize storage
- Built-in video management system
- Integrated video wall interface with live camera feeds / Smart event filters for quick access to relevant video recordings / Interactive timeline with preview navigation for efficient playback and incident review
- Visual verification of Ajax system alarms
- Privacy
- Accelerometer
Power supply3
- Main
- 100–240 V / 50/60 Hz / 0.6 A
- Power consumption
- up to 60 W
- Clock battery
- CR2032 battery / 3 V
Enclosure5
- Dimensions
- 330 × 330 × 44 mm
- Weight
- TBC kg
- Operating temperature range
- from 0 °C to +50 °C
- Operating humidity
- up to 75%
- Protection class
- IP20
