Availability: In stock
Product Code:24948
Description:
* In order to use the Smart Dual Light HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000004.1.R.220323 or later version.
- Max. 30 fps@1080p
- 3D NR
- Smart Dual Light
- 20 m illumination distance
- Super Adapt
- Built-in mic
- 3.6 mm fixed lens
- CVI/CVBS/AHD/TVI switchable.
- IP67, 12 VDC
Details:
Camera
- Image Sensor : 2 MP CMOS
- Max. Resolution : 1920 (H) × 1080 (V)
- Scanning System : Progressive
- Electronic Shutter Speed : PAL: 1/25 s–1/100000 s / NTSC: 1/30 s–1/100000 s
- Min. Illumination : 0.01 lux@F2.0 (Color, 30 IRE) / 0.001 lux@F2.0 (B/W, 30 IRE) / 0 lux (Illuminator on)
- S/N Ratio : >65 dB
- Illumination Distance : IR: 20 m / Warm light: 20 m
- Illuminator On/Off Control : Auto
- Illuminator Number : 2 (Warm light);2 (IR light)
Lens
- Lens Type : Fixed-focal
- Auto Focus : No
- Lens Mount : M12
- Focal Length : 3.6 mm
- Max. Aperture : F2.0
- Field of View : 3.6 mm: H: 83°; V: 48°; D: 105°
- Iris Control : Fixed
- Close Focus Distance : 3.6 mm: 0.7 m
Video
- Video Frame Rate : CVI: PAL: 1080p@25 fps; NTSC: 1080p@30 fps; / AHD:
- PAL: 1080p@25 fps; NTSC: 1080p@30 fps; / TVI: PAL: 1080p@25 fps; NTSC: 1080p@30 fps; / CVBS: PAL: 960H; NTSC: 960H
- Resolution : 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
- Day/Night : Auto(ICR)/Color/B/W
- BLC : BLC; HLC; DWDR
- WDR : DWDR
- White Balance : Auto Area white balance
- Gain Control : Auto
- Noise Reduction : 3D NR
- Illumination Mode : Smart IR&WL; WL Mode; IR Mode
- Mirror : Yes
- Privacy Masking : Off/On (8 areas, rectangle)
Certification
- Certifications : CE-LVD: EN 62368-1; / CE-EMC: EN 55032; EN 55035; / FCC: 47 CFR FCC Part 15, Subpart B
Port
- Video Output : Video output choices of CVI/TVI/AHD/CVBS by one BNC port
- Audio Input : 1 channel
Power
- Power Supply : 12 VDC ± 30%
- Power Consumption : Max 2.6W (12 VDC, IR on)
Environment
- Operating Temperature : –40 °C to +60 °C
- Operating Humidity : <95% (RH), non-condensing
- Storage Temperature : –40 °C to +60 °C
- Storage Humidity : <95% (RH), non-condensing
- Protection :IP67
Structure
- Casing Material : Plastic
- Product Dimensions : 163.4 mm × 69.7 mm × 70 mm
- Net Weight : 0.18 kg
- Gross Weight : 0.26 kg
- Installation : Wall mount; ceiling mount; vertical pole mount
