Description:
- 4-MP 1/3" CMOS image sensor, low luminance, and high definition image
- Outputs max 4 MP (2560 × 1440)@25/30 fps
- H.265 codec / high compression rate / ultra-low bit rate
- Built-in warm light / the max warm light distance is 30 m
- WDR / 3D NR / HLC / BLC / digital watermarking / applicable to various monitoring scenes
- ROI / Super AI Coding (H.265/H.264) / flexible coding / applicable to various bandwidth and storage environments
- Abnormality detection: Motion detection / video tampering / audio detection / network disconnection / IP conflict and illegal access
- Built-in Mic
- 12 VDC / PoE power supply
- IP67 protection
- Supports human and vehicle detection
Details:
Camera
- Image Sensor : 1/3" CMOS
- Max. Resolution : 2560 (H) × 1440 (V)
- Scanning System : Progressive
- Electronic Shutter Speed : Auto/Manual 1/3 s–1/100,000 s
- Min. Illumination : 0.0005 lux@F1.0
- S/N Ratio : >56 dB
- Illumination Distance : 2.8 mm: Up to 20 m (65.62 ft) (Warm light) / 3.6 mm: Up to 30 m (98.43 ft) (Warm light)
- Illuminator On/Off Control : Auto / Manual
- Illuminator Number : 1 (Warm light)
- Angle Adjustment : Pan: 0° to 360° / Tilt: 0° to 78° / Rotation: 0° to 360°
Lens
- Lens Type : Fixed-focal
- Lens Mount : M12
- Focal Length : 2.8 mm
- Max. Aperture : F1.0
- Field of View : 2.8 mm: H: 95° / V: 50° / D: 112°
- Iris Control : Fixed
- Close Focus Distance : 2.8 mm: 2 m (6.56 ft)
Intelligence
- SMD : SMD Plus
- Smart Search : Works together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
- Video Compression : H.265 / H.264 / H.264H / H.264B / MJPEG (Only supported by sub stream)
- AI Coding : Super AI Coding (H.265) / Super AI Coding (H.264)(*Includes smart codec technology, Smart H.265+ and Smart H.264+)
- Video Frame Rate : Main stream: 2560 × 1440@(1–25/30 fps) / Video Frame Rate / Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30fps)
- Streaming Capability : 2 streams
- Resolution : 4M (2560 × 1440) / 3M (2304 × 1296) / 1080p (1920 × 1080) / 1.3M (1280 × 960) / 720p (1280 × 720) / D1 (704 × 576/704 × 480) / VGA (640 × 480) / CIF (352 × 288/352 × 240)
- Bit Rate Control : VBR / CBR
- Video Bit Rate : H.264: 32 kbps–4096 kbps / H.265: 12 kbps–4096 kbps
- Day/Night : Color/B/W
- BLC : Yes
- HLC : Yes
- WDR : 120 dB
- White Balance : Auto / Natural / Street Lamp / Outdoor / Manual / Regional Custom
- Gain Control : Manual / Auto
- Noise Reduction : 3D NR
- Motion Detection : OFF/ON (4 areas / rectangular)
- Region of Interest (RoI) : Yes (4 areas)
- Smart Illumination : Yes
- Image Rotation : 0°/180°
- Mirror : Yes
- Privacy Masking : 4 areas
Audio
- Built-in MIC : Yes / built-in Mic
- Audio Compression : G.711a / G.711Mu / PCM / G.726
Alarm
- Alarm Event : Network disconnection / IP conflict / illegal access /
- motion detection / video tampering / audio detection / SMD / security exception
Network
- Network Port : RJ-45 (10/100 Base-T)
- SDK and API : Yes
- Network Protocol : IPv4 / IPv6 / HTTP / TCP / UDP / ARP / RTP / RTSP / RTCP / RTMP / SMTP / FTP / DHCP / DNS / DDNS / NTP / Multicast / ICMP / IGMP / NFS / P2P / Auto Registration
- Interoperability : ONVIF (Profile S & Profile T) / CGI
- User/Host : 6 (Total bandwidth: 24 M)
- Storage : FTP
- Browser : IE / Chrome / Firefox
- Management Software : Smart PSS Lite / DSS / DMSS / DoLynk Care
- Mobile Client : iOS / Android
- Security : Digest / WSSE / Account lockout / Security logs / IP/MAC filtering / Generation and importing of X.509 certification / syslog / HTTPS / Trusted boot / Trusted execution / Trusted upgrade / Session security / Security warning / SSL/TLS1.2 / AES 256
Certification
- Certifications : CE-LVD: EN62368-1 / CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
Power
- Power Supply : 12 VDC (±30%) / PoE (802.3af)
- Dual Power Backup : Yes
- Power Consumption : Basic: 1.6 W (12 VDC) / 2.5 W (PoE) / Max.: 4.1 W (12 VDC) / 5.3 W (PoE) (ICR switch + AI ISP on + illuminator intensity)
Environment
- Operating Temperature : –40 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity : ≤95% (RH) / non-condensing
- Storage Temperature : –40 °C to +60 °C (–40 °F to +140 °F)
- Storage Humidity : ≤95% (RH) / non-condensing
- Protection : IP67
- Anti-corrosion Level : Basic Protection
Structure
- Casing Material : Inner core : Metal + Plastic / Cover: Plastic / Decoration ring: Plastic / Pedestal: Plastic
- Product Dimensions : 85.5 mm × Φ109 mm (3.37" × Φ4.29")
- Net Weight : 0.25 kg (0.55 lb)
- Gross Weight : 0.38 kg (0.84 lb)
