Dahua VD IP Doorphone Villa Camera VTO6631QB-WP (Black)

653,00 €

Out of stock

Out of stock

Free store pick-up in Limassol · Delivery across Cyprus from €6

Dahua VD IP Doorphone Villa Camera VTO6631QB-WP (Black)
Dahua VD IP Doorphone Villa Camera VTO6631QB-WP (Black)
653,00 €

Or contact us directly:

📞 25 102 760
📱 96 401 000

Specifications

System6
Main Processor
Embedded Processor
Operating System
Embedded Linux OS
Button Type
Mechanical
Number of Buttons
1
Interoperability
ONVIF / CGI
Network Protocol
RTSP / DNS / FTP / RTP / RTMP / SIP / SSH / HTTP/HTTPS / ONVIF
Basic18
Screen Type
Capacitive Touchscreen
Display Screen
5-inch display screen
Screen Resolution
720 (H) × 1280 (V)
Camera
1/2.8" 2 MP CMOS high-definition / low illumination / dual cameras
Field of View
H: 119° / V: 66° / D: 142°
WDR
120 dB
Noise Reduction
3D NR
Video Compression
H.264 / H.265
Video Resolution
Main stream: 720P/D1/WVGA/CIF / Sub stream: 1080P/720P/D1/WVGA/CIF/QVGA
Video Frame Rate
PAL: 25 fps / NTSC: 30 fps
Video Bit Rate
256 kbps–4,096 kbps
Light Compensation
Auto IR
Audio Compression
G.711a / G.711u / PCM
Audio Input
1 channel
Audio Output
Built-in speaker
Audio Mode
Two-way audio
Audio Enhancement
Echo suppression/digital noise reduction
Audio Bit Rate
16 kHz, 16 bit
Function13
Communication Mode
Full digital
Verification Method
Card / Password / Face Recognition / Bluetooth
Frequency Range
2400-2483.5 MHz
Max. Transmission Power
CE EIRP : ≤20 dBm@2400-2483.5 MHz
Bluetooth
Yes
Bluetooth Standard
BLE (Bluetooth mode) / BT5.2 (Bluetooth version)
Auto Snapshot
Yes
Information Release
Receive and view text information released by the management center
Elevator Control
Residents and visitors can call elevators. Permissions can also be granted to access floors through access control
Leave Videos
Yes (SD card inserted in VTO is needed)
Storage
Supports Micro SD card (up to 128 GB)
Web Configuration
Yes
Auto Registration
Yes
RFID4
Card Type
IC card / ID card
Modulation Type
ASK
Frequency Range
IC:13.56 MHz / ID:125 kHz
Max. Transmission Power
IC:42 dBuA/m @10m / ID:66 dBuA/m @10m
Network4
Max. Transmission Power
≤20 dBm@2400-2483.5 MHz
Wi-Fi
Yes
Wireless Standard
IEEE802.11b/802.11g/802.11n
Wireless Frequency Range
2.4 GHz
Performance6
Card Reading Distance
0 cm–3 cm
Face Recognition Height Range
1.2 m–2.0 m
Face Recognition Distance
0.3 m–2.0 m
Face Recognition Accuracy
99.9%
Face Recognition Time
0.2 s
Casing Material
Tempered glass / PC + ABS
Capacity3
Card Capacity
100,000
Face Image Capacity
20,000
User Capacity
20,000
Port9
RS-485
1 channel
Wiegand
1 channel
Alarm Input
2 channels
Alarm Output
1 channel
Power Output
Max 12 V / 1.5 A through an adapter / Max 12 V / 0.5 A through PoE
Exit Button
1 channel
Door Status Detection
1 channel
Lock Control
1 channel / open by default
Network Port
1 × 10 Mbps/100 Mbps Ethernet port
Alarm1
Tamper Alarm
Yes
General16
Appearance Color
Dark Silver
Power Supply
Standard PoE / 12 VDC / 3 A
Power Adapter
Optional
Installation
Surface Mount
Certifications
CE
Accessory
Power supply (optional) / Surface Mounted (standard)
Product Dimension
186.8 mm × 81.4 mm × 23.3 mm (H × W × D)
Protection
IP65 rated (Silicone sealant is required.)
Operating Temperature
–30 °C to +60 °C
Operating Humidity
0%–90% (RH) / non-condensing
Operating Environment
Outdoor
Operating Altitude
0 m–1,300 m
Power Consumption
≤ 8 W (standby) / ≤ 10 W (working). These two values of power consumption do not contain the output power.
Gross Weight
0.82 kg
Storage Temperature
–20 °C to +70 °C
Storage Humidity
30%–75%
  • Ultra-thin frame design
  • 5-inch IPS screen with a high resolution of 720 × 1280
  • 2 MP wide angle camera with H : 119° / V: 66° / D: 142° FOV
  • Unlocks through IC and ID cards / Bluetooth cards / face and password
  • Supports 20,000 users / 20,000 faces / 20,000 passwords / 100,000 IC and ID cards / 20,000 Bluetooth cards and 200,000 records
  • Recognizes faces 0.3 to 2 m away (0.98 to 6.56 ft), and has a face recognition accuracy rate of 99.9% and a one to many identification time of 0.2 sec per face
  • The theme can be personalized, making it suitable for a wide variety of scenes
  • Provides power to the card reader and electromagnetic lock, offering max 12 V, 0.5 A through PoE, and 12 V, 1.5 A through an adapter
  • IP65 rated (Silicone sealant is required for the flush mount plate)
  • TCP/IP and Wi-Fi connection.
  • PoE power supply
