Availability: In stock
Product Code:21165
Description:
NC lock = Normally Closed
No power → unlocked
Power ON → locks
NC = Needs power to stay closed
- Surface mounted, no need to drill a hole on frame, Safe & Durable
- Lower power consumption, Enviromental protection
- Auto-relock if no Action within 5 secs
- Working Measure: power-on to lock
- Suitable for: Wooden Door,Glass Door,Metal Door,Fire Proof Door
- Input Voltage: DC12V
- Working Current: 900mA; Static Current: 100mA.
- Working Measure: Fail secure, unlock when energized
- Fail-safe type: Power to lock (The lock is NC)
- Dimension: L150xW34xH28(mm)
- Operating temp: -10~+25℃
- Operating Humidity: 0~90%
- Special Designed: Tested to 500000 cycles
- Face place material：Zinc Alloy, Carrulous Line Finished
- Door status signal output contact (NO/COM)
- Weight: 0.6Kg
