- Power over Ethernet
- Person/Vehicle Detection
- With 16-Channel NVR
- 4TB HDD Built-In
Reolink POE IP Dome Camera 12MP Fixed RLC-1224A (P344)
119,99 €
Dahua IP 8.0MP Bullet 3.6mm WDR HFW2849T-AS-IL-0360B-BLACK
407,00 €Reolink KIT 16xChNVR+8x8MP Dome+4TB RLK16-800D8-8MP
899,00 €
In stock · delivery across CyprusFree pickup in Limassol
Pairs well with
Popular add-ons for this product
Code: 27960- Length: 1.8 m
- Power: 100W
In stock · delivery across CyprusFree pickup in Limassol19,99 €Add to cart
More options
Similar IP Cameras & NVR in a similar price range
Specifications
Video/Audio Input2
- IP Video Input
- PoE IP camera x 16
- Audio Input
- Cameras with built-in mic
Video/Audio Output3
- Video Output
- VGA, HDMI
- Display Resolution
- HDMI: 4096*3072, 3840*2160, 1920*1080, 1440*900, 1280*1024, 1280*800, 1280*720, 1024*768 / VGA: 1920*1080, 1440*900, 1280*1024, 1280*720, 1024*768
- Audio output
- 1-channel, RCA
Decoding3
- Live View/Playback Resolution
- 7680×2160, 4608×1728, 4512×2512, 4096×3072, 3840×2160, 2560×2560, 2560×1920, 2560×1440, 2048×1536, 2304×1296, 1080p, 720p
- Video Format
- H.265, H.264
- Synchronous Playback
- Up to 4 channels
HDD3
- SATA
- 2 x SATA interface (1 x Seagate 4TB HDD included)
- Capacity
- Up to 12TB (Max. 6TB capacity for each HDD)
- External HDD
- No
External Interface2
- USB Interface
- 2 x USB 2.0
- Network Interface
- 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface for LAN/WAN / 16, RJ-45 10/100 Mbps self-adaptive PoE Ethernet interface for IP camera
PoE2
- Max. Power Per Port
- 25W
- Supported Standard
- IEEE 802.3 af/at
Network4
- Network Protocol
- HTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
- Browser Supported
- Firefox, Chrome, Edge, Safari
- OS Supported
- PC: Windows, Mac OS; Smartphone: iOS, Android
- Max. User Access
- 20 users (1 admin account & 19 user accounts); supports up to 12 simultaneous video streams (10 substreams & 2 mainstreams)
General5
- Power Supply
- DC 52V/2.88A
- Power Consumption
- <10W (without HDD&PoE)
- Working Environment
- Temperature: -10°C~+55°C (14°F~131°F) / Humidity: 10%~90%
- Dimensions
- 330 x 45 x 285mm
- Weight
- 2.4kg
Video & Audio10
- Image Sensor
- 1/2.49" CMOS Sensor
- Video Resolution
- Default: 3840X2160 (8 megapixels) @20FPS
- Lens
- f=4.0 mm fixed, F=2.0, with IR cut
- Video Format
- H.265
- Field of View
- Horizontal: 87° Vertical: 44°
- Day & Night
- IR-cut filter with auto-switching
- Night Vision
- 30 meters (100ft) (LED: 18pcs/14mil/850nm)
- Frame Rate
- Mainstream: 2fps - 20fps (default: 20fps) / Substream: 4fps - 15fps (default: 10fps)
- Code Rate
- Mainstream: 4096Kbps - 8192Kbps (default: 6144Kbps) / Substream: 64Kbps - 512Kbps (default: 256Kbps)
- Audio
- Audio recording
Detection/Recording Modes2
- Smart Alarms
- Person detection/vehicle detection/motion detection
- Recording Modes
- Motion-triggered recording (default); scheduled recording, 24/7 recording
Power2
- PoE
- IEEE 802.3af, 48V Active
- DC Power
- DC 12.0V⎓ 1A, <12W
Interface4
- Power
- DC power port
- System
- Reset button
- Ethernet
- One 10M/100Mbps RJ45
- Audio
- Built-in microphone
Working Environment3
- Temperature
- Operating temperature: -10°C~+55°C
- Humidity
- Operating humidity: 10% ~ 90%
- Waterproof
- IP67
Size & Weight2
- Dimension
- Φ66 x 192mm
- Weight
- 480g
